INTRODUCTION FOR ENGINEERING DRAWING UNDERSTANDING

This course covers the majority of information required to understand basic mechanical two-dimensional engineering drawings. Topics covered are:

• Basic drawing elements (formats, title block, parts list, revision block, etc.)
• Part views (multiview, auxiliary, and isometric)
• Section views
• General dimensions
• Tolerances

COURSE OBJECTIVES

This training helps participants :

• Describe the fundamentals of drawing interpretation
• Identify drawing elements, including part views and sections
• Describe general dimensions and tolerances
• Explain how to present surface texture

INTENDED AUDIENCE

Beginning designers, drafters, quality, procurement, tooling, production, manufacturing and shop personnel; more advanced designers, and those involved with tooling, production, inspection, routing in the shop; others involved with purchasing, costing and management; vendors and suppliers.

METHODOLOGY

• This workshop will be interactive and action based with personal examples.
• Feedback from the trainer on your own writing.
• Participants are to bring along their drawings for discussion.

OUTLINE OF WORKSHOP

1. Drawing Interpretation

1. Introduction
2. Draw production
3. Standards

2. Drawing Layout

1. Parts of two-dimensional drawings
2. Sizes and codes

3. Part Views

1. View projection
2. Projection systems
3. Surface types
4. Line types
5. Multiview drawing visualization
6. Exercises

4. Auxiliary Views

1. Define and recognize auxiliary views
2. Successive auxiliary views
3. Partial Views
4. Secondary auxiliary view
5. Exercise

5. Isometric and Oblique Views

1. Pictorial Views
2. ASME Y14.4 Pictorial Drawings standard
3. Oblique Projection
4. Exercises

6. Section Views

1. Section line patterns
2. Section types
3. Exercises – Quiz

7. General Dimensioning

1. ASME Y14.5-2009 Dimensioning and Tolerancing standard
2. Feature types
3. Dimension elements
4. Dimension construction
5. General dimensions
6. Exercises
7. Quiz

8. Tolerances

1. Size Features
2. Dimension Expression
3. Terminology
4. Envelope Principle
5. Dimensioning Rules
6. Tolerance Allocation
7. Exercises
8. Quiz

9. Surface Texture

1. Surface Texture Symbols and Characteristics
2. Proper placement of surface characteristics on a surface texture symbol
3. Exercises
4. Quiz
