ELECTRICAL ENGINEERING FOR NON -ELECTRICAL PERSONNEL

Share:

INTRODUCTION FOR ELECTRICAL ENGINEERING FOR NON -ELECTRICAL PERSONNEL

Most of the machine in manufacturing industry using electrical system to control and generates desire output based on production process. The Technician must have basic knowledge and understanding of electrical system to perform daily task assign by Supervisor or Manager. However, some of technicians came from mechanical or non- electrical engineering disciplines.

To ensure effectiveness of production output and minimize machine breakdown delay time, the technician must be able to assist senior technician or engineer by monitoring operation of electrical system. He/she will report to senior technician or engineer if machine in fault conditions and able to response the problems as” first line repair technician”. OTC Training Centre provide training module as Electrical for Non-Electrical Personnel Training by sharing practical session and technical skill with easy technique especially for Non Electrical Personnel.



Electrical for Non- Electrical Personnel Training will expose the participants on:

  • Introduction to Electrical basic principle
  • Introduction to Electrical system and wiring diagram
  • Introduction to Electrical component and basic function
  • Application of Digital Multi Meter and Test Pen
  • Safety precaution on electrical system
  • Generate basic electrical wiring on Parallel and Series Circuit
  • Perform voltage and current measurement
  • Testing and verify status of electrical components



THIS TRAINING IS SUITABLE FOR

  • Maintenance Department
  • Production Department
  • Service Department



COURSE OBJECTIVE

To equipped the participants on:

  • Electrical Basic principle
  • Electrical system and wiring diagram
  • Electrical component and basic function
  • Application of Digital Multi Meter and Test Pen
  • Safety precaution on electrical system
  • Generate basic electrical wiring on Parallel and Series Circuit
  • Perform voltage and current measurement
  • Testing and verify status of electrical components



LEARNING OUTCOME

After completed this training, the technician will be able to:

  • Identify component symbol, specification and basic function
  • Understanding of electrical machine basic design
  • Understanding basic operation of electrical wiring system for 1 phase & 3 Phase.
  • Application of Digital Multi Meter , Test Pen and Insulation Tester
  • Alert to Safety precaution on electrical system
  • Identify component part no
  • Generate basic electrical wiring on Parallel and Series Circuit
  • Perform voltage and current measurement
  • Testing and verify status of electrical components



COURSE CONTENT

DAY1

Introduction to electrical basic principle

  • What is electricity?
  • Electrical Symbol
  • Unit of Electrical Measurement
  • Ohms Law & calculation



Introduction to basic electrical System and wiring diagram

  • Electrical system block diagram
  • Single phase / Domestic wiring
  • 3 Phase / industrial wiring



Introduction to Electrical Component & basic function

  • Power Devices
    • Fuses / Main Circuit Breaker / AC Filter / Power Supply
  • Control Devices
    • Programmable Logic Controller / Magnetic contactor / AC Relay / DC Relay / Solid state Relay / Timer
  • Output / Load Devices
    • Lamp / Heater Assembly / Single phase Motor / 3 phase Motor / Buzzer



Application of Test Equipment

  • Digital Multi meter
  • Test Pen – Current Detector



Safety Precaution on Electrical System



Practical 1- Electrical wiring 2 load in series

  • Measurement of ac voltage
    • AC Input / load1 / load2
  • Measurement of ac current
    • IT(Total) / I1(Load1) / I2 (load 2)



Practical 2- Electrical wiring 2 load in parallel

  • Measurement of ac voltage
    • AC Input / load1 / load2
  • Measurement of ac current
    • IT(Total) / I1(Load1) / I2 (load 2)



Practical 3- Electrical wiring with AC bulb and control by DC Circuit (Solid State Relay)

  • Measurement of ac voltage
    • AC Input / SSR_1/SSR_2/ Bulb
  • Measurement of ac current
    • IT(Total) / I SSR_1 / I SSR_2 / I bulb
  • Measurement of DC Voltage
    • Battery Voltage/ SSR min ON voltage



Practical 4 – Testing and Verify status of electrical component.

  • Fuse
  • Switching Power Supply
  • Magnetic Contactor
  • AC Relay
  • DC Relay
  • Solid State Relay
  • Heater
  • AC Motor
  • Condenser/ Capacitor
